BMN Dyes and Quenchers


BMN Dyes– Dyes from biomers.net

BMN-488, BMN-505, BMN-536, BMN-562


In addition to the wide range of known fluorescent dyes, biomers.net also offers its own excellent alternatives.
The so-called BMN dyes can be attached to an oligonucleotide at the 5´- or 3´-end.

Dye                ABS [nm]              EM [nm] Alternative to
     BMN-488 495 519 Atto 488, Alexa Fluor 488® (identical structure)
     BMN-505 507 524 Fam, Fluorescein, FITC
     BMN-536 536 553 Carboxyrhodamin 6G, Atto Rho6G
     BMN-562 562 578 Rhodamin B
     BMN-5 * 645 671 Cyanine 5
     BMN-6 * 681 704 Cyanine 5.5


* Due to the changed patent situation of the cyanines, we recommend the use of the analog cyanine dyes Cyanine 5 (analog BMN-5) and Cyanine 5.5 (analog BMN-6).

BMN Quencher – Quenchers from biomers.net

BMN-Q460, BMN-Q535, BMN-Q1, BMN-Q2, BMN-Q620


In addition to this wide range of available quenchers, biomers.net also offers a "proprietary" quencher set.
The BMN quenchers of biomers.net are excellent alternatives to the traditional Dark Quenchers due to their optimal matching quenching range.


Quencher ABS [nm] Quenching Range [nm] Alternative to
     BMN-Q460 453 400-530 Dabcyl, DDQ I
     BMN-Q535 535 480-580 BHQ-1, TQ2, DDQ I, Iowa Black FQ, Eclipse-Quencher, Dabcyl
     BMN-Q1 535 480-580 BHQ-1, TQ2, DDQ I, Iowa Black FQ, Eclipse-Quencher, Dabcyl
     BMN-Q2 580 500-650 BHQ-2, TQ3
     BMN-Q590 590 550-650 will be discontinued
     BMN-Q620 620 480-720 BHQ-2, TQ3, BBQ-650, DDQ II, Iowa Black RQ
     BMN-Q651 650 550-720 BBQ-650, DDQ II
                              BMN quencher set: dT20 oligo with 3´-quencher, measurement of absorption  spectra in buffer (pH 7.0)

Figure1: dT20 oligo with 3´-quencher, meaurement of absorption spectra in buffer (pH 7.0)


BMN-Q460

With an absorption maximum of 460 nm, our Dark Quencher BMN-Q460 is particularly suitable for the short-wavelength region and represents an excellent alternative for the quenchers Dabcyl and DDQ I.
In addition to use in Molecular Beacons, in which it inhibits fluorescent signals by contact-quenching, BMN-Q460 can be used in various molecular biological applications. As 3´-quencher in Dual-Labelled probes (5´-nuclease assay), BMN-Q460 can be used in the range of 400-530 nm, so it is ideally suited for the fluorophores Atto 390, Atto 425 and Atto 465.
biomers.net offers the quencher BMN-Q460 as 5´-, 3´- or internal modification.


BMN-Q535

BMN-Q535 is the second Dark Quencher of biomers.net and has an absorption maximum at about 535 nm and a quenching range from about 480 nm to 580 nm. This is the same range as BHQ-1, TQ2, DDQ I, Eclipse-Quencher or Iowa Black FQ, so BMN-Q535 may be an excellent alternative for this quenching.
BMN-Q535 is used as 3'-modification for standard Dual-Labelled Probes and Molecular Beacons.
We offer this quencher as 5 'or 3 modification. In addition, BMN-Q535 can be used as internal modification in Double Quenched probes with increased sensitivity.


               Dual-Labelled Probe              Double Quenched Probe              Molecular Beacon Probe
dual-labelled probe DoubleQuenched probe Molecular Beacon


BMN-Q1 and BMN-Q2

BMN-Q1 and BMN-Q2 are direct alternatives with identical specifications to BHQ-1 and BHQ-2.


BMN-Q620

Similar to the quenchers BMN-Q460 and BMN-Q535, biomers.net also offers the dark quencher BMN-Q620 as
5´, 3´ and internal modification. Thus, BMN-Q620 can be used ideally in Double Quenched Probes for the longer wavelength region. With an absorption maximum of 620 nm and a quenching range of 480 nm to 720 nm, it has a relatively wide range and can therefore optimally quench fluorescence dyes also in the long-wave range, e.g. Cyanine 5 or Cyanine 5.5.


BMN-Q651

With an absorption maximum at 650 nm and a quenching range of 550-720 nm, the biomers.net quencher BMN-Q651 optimally covers the longer wavelength range. BMN-Q651 can be used as an alternative to BBQ-650 or DDQ II.
